MSI - Fan module - Cooling System MAG coreliquid- Panamá - REBELLIOUS AND DISTINCT
The MAG CORELIQUID C Series liquid coolers' water block features a large surfaced ARGB lighting that is sure to dazzle your build. It is split into four pieces of unique diamond-cut areas, with three capable of lighting up and the last one featuring our proud MSI logo emblem.

NEXT-GEN AMD SOCKET AM5 SUPPORT
AMD Socket AM5 (LGA 1718) is the next-generation socket designed to support next-generation AMD Ryzen™ 7000 desktop processors (Zen 4). AMD Socket AM5 uses the same liquid cooler bracket as Socket AM4*. This allows you to upgrade to and enjoy AM5 without buying a new liquid cooler.

LGA 1700 COMPATIBLE
The MAG CORELIQUID C Series liquid cooler provides out of box support for LGA 1700.

RADIATOR PUMP DESIGN
The pump has been integrated into the radiator for sound dampening and noise reduction. Additionally, placing the pump into the radiator also increases the pump's life expectancy by moving it away from the heat source.

HIGH THERMAL DISSIPATION
A split pathway through the radiator rapidly dissipates heat, cooled liquid is then pumped back into the loop.

PUMP MOTOR
RESONANCE ELIMINATION
A durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.

EVAPORATION PROOF TUBING
Constructed with three layers of netted plastic tubing and a reinforced mesh exterior.

EXTENSIVE COMPATIBILITY
Stylish yet built for flexibility, the MAG CORELIQUID C Series has been designed with a secure installation bundle with compatibility on a number of Intel and AMD motherboards.

Intel Socket
LGA 1150/1151/1155/1156/1200/1700
LGA 1366/2011/2011-3/2066

AMD Socket
AM5/AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2

Specifications

Performance

• Suitable location: Processor
• Type: All-in-one liquid cooler
• Fan diameter: 12 cm
• Supported processor sockets: LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM4, Socket AM5, Socket FM1, Socket FM2+
• Maximum airflow: 78.73 cfm
• Pulse-width modulation (PWM) support: Yes
• Bearing type: Dual ball bearing
• Fan noise level (min): 14.3 dB
• Fan noise level (max): 34.3 dB
• Pump noise level: 18 dB
• Quantity per pack: 1 pc(s)
• Pump motor speed: 4200 RPM
• Fan speed (min): 500 RPM
• Fan speed (max): 2000 RPM
• Fan static pressure: 2.39 mmH2O
• Pump's mean time to failure (MTTF): 100000 h
• Fan's mean time to failure (MTTF): 70000 h

Design

• Product colour: Black
• Material: Aluminium
• Radiator material: Aluminum
• Number of fans: 2 fan(s)
• Illumination LED: Yes
• Illumination colour: Multi
• Fan connector: 4-pin + 4-pin

Power

• Fan power consumption: 1.8 W
• Pump power consumption: 4.08 W
• Pump voltage: 12 V
• Pump current: 0.34 mA
• Fan voltage: 12 V
• Fan current: 0.15 A

Weight & dimensions

• Radiator width: 27.6 cm
• Radiator depth: 12 cm
• Radiator height: 2.7 cm
• Tube length: 40 cm
• Waterblock width: 7.05 cm
• Waterblock depth: 7.05 cm
• Waterblock height: 5.2 cm
• Fan dimensions (W x D x H): 120 x 120 x 25 mm
• Cable length: 0.55 m

Packaging content

• Cables included: Fan

Other features

• Air pressure: 2.39 mmH2O
